Mine Machinery Hydraulic Rock Breaker Korean Cylinder For Hyundai
Excavator R500
Hydraulic breakers are widely applied to rock broken, mining, road,
building engineering, dismantling engineering and special
engineering (underwater project, tunnel project), etc. Our breaker
includes side type, top type, silenced type and backhoe loader type
breaker.
Description
1. Supplied ready to use with hydraulic hoses, tool, N2 gas
charging kit
2. Easy fitment onto any kinds of excavators
3. Durable body incorporating heavy duty rock claws
4. Perfectly matched tool and piston ensure maximum energy transfer
to the material being broken
5. The hydraulic accumulator gives greater acceleration in the
power stroke and reduces pressure peaks in the carrier hydraulic
system.
Specification
| Model | Weight (Kg) | Length (Mm) | Pressure (kg/cm2) | Flux (L/Min) | Rate (Bpm) | Hose (Inch) | Chisel (Mm) | Suit (Ton) |
| JSB200 | 100/120 | 1100 | 90-120 | 15-25 | 700-1200 | 1/2 | 45/53 | 1.2-3.0 |
| JSB400 | 298 | 1347 | 110-140 | 25-45 | 500-900 | 1/2 | 68/70 | 3.0-5.5 |
| JSB600 | 421 | 1528 | 110-160 | 30-45 | 500-800 | 1/2 | 75 | 4.0-7.0 |
| JSB800 | 577 | 1920 | 120-170 | 45-85 | 400-700 | 3/4 | 85 | 7.0-14 |
| JSB900 | 973 | 2260 | 150-170 | 80-120 | 400-700 | 3/4 | 100 | 11-16 |
| JSB1600 | 1855 | 2695 | 160-180 | 120-160 | 400-700 | 1 | 135 | 19-26 |
| JSB1900 | 1989 | 2810 | 160-180 | 130-170 | 400-600 | 1 | 140 | 19-26 |
| JSB2800 | 2420 | 2895 | 160-180 | 150-190 | 350-500 | 1 | 150 | 27-38 |
| JSB3500 | 2750 | 3152 | 160-180 | 170-220 | 250-400 | 1 | 155 | 28-40 |
| JSB4500 | 3160 | 3310 | 160-180 | 200-300 | 250-350 | 1.25 | 165 | 36-45 |
| JSB5000 | 4210 | 3400 | 160-180 | 210-290 | 200-350 | 1.25 | 175 | 40-55 |
| JSB5500 | 4720 | 3400 | 180-220 | 220-300 | 200-250 | 1.25 | 185 | 50-60 |
| JSB6000 | 4910 | 3420 | 180-220 | 230-320 | 180-200 | 1.25 | 190 | 55-65 |
| JSB6500 | 6100 | 3700 | 190-230 | 360-450 | 120-200 | 1.25 | 210 | 65-100 |
Application
1. Mining: Mountains, mining, crushing, secondary crushing
2. Metallurgy, slag cleaning, ladle furnace demolition, demolition
equipment foundation body dissatisfied
3. Railway, tunnel, bridge, mountain down.
4. Highway: highway repair, cement pavement broken, foundation
excavation.
5. Municipal gardens, concrete crushing, gas engineering
construction, the transformation of the old city.
6. Building: the old building demolition, reinforced concrete
broken.
Company Introduction
Jisan Heavy Industry Ltd. is a leading manufacturer of hydraulic
breaker and attachments, widely used in the construction,
demolition, mining industries and special project. At present, the
capacities of research and development, and manufacturing and the
level of quality control stand at the forefront of the industry
regarding comprehensive strength.
After nearly ten years of development, we process a professional
and experienced technical research team, We have over 300
employees, includes over 40 engineers, production workshop cover
30,000 square meters. With advanced testing equipments, leading
R&D capability, and LPS production line, the company has passed
authentication of BV, SGS, and CE certification. Quality is the
life of enterprise! Grasp the quality source in all the details.
